Independent Multi heating cooling Chamber Water Bath

Labtro Manufacturer , exporter and supplier of Labtro Microprocessor Technology Multi Chamber Cooling and heating Water Bath, Circulating Water Bath, Digital Circulating Oil Bath, Ultrasonic Cleaner, Cooling Viscosity Bath and water bath shaker incubator shaker.

multi-water-bath

Multi Chamber Water Bath

Labtro Two / Three / four Independent Chambers have Independent Controls for Operating at Different Temperatures as per request magnetic stirrer also on request. Microprocessor based Labtro multi chamber water bath. Control for 0.1oCAccuracy.Temperature Timer, low temperature Alarm, high temperature alarm, over safety temperature water bath Auto-Tuning Function. Labtro Multi chamber water bath Precise Temperature Control up to 99°C. Labtro Water bath chamber Built-in drier protection Safety and Convenience. Labtro Multi Chamber water bath Seamless Stainless Steel Bath (SS304).Labtro Water Baths Chamber Design has independent controls for operating at different temperatures and different rpm on request, Used for industrial, pharmaceutical, laboratory clinical and biomedical use.Laboratory multi chamber Digital Microprocessor Controller Accuracy ± 1° stability , ± 0.5°C accuracy, Laboratory Multi Chamber Water Bath temperature range from ambient to 99°C. Multi chamber Microprocessor based controller membrane type touch type door mount controller with timer, alarm and auto-tuning function. Labtro Water Bath chamber Seamless Stainless Steel corrosion resistant (Grade SS 304) water bath Over Temperature Protection & over current leakage breaker ensure user safety Drain Valve / Drain valve outlet you easily drain off / Drain valve.Multi Chamber Water Bath with the independent controller and stirrer optional.

LABTRO WATER BATH SIZE :-

Model Single Chamber size WxDXH
LWB-6 300mmx250mmx100mm
LWB-9 300mmx350mmx100mm
LWB-12 350mmx400mmx100mm



Labtro Water Bath

Labtro Manufacturer , exporter and supplier of Labtro Microprocessor Technology Multi Chamber Cooling and heating Water Bath, Circulating Water Bath, water bath , digital water bath, Digital Circulating Oil Bath, Ultrasonic Cleaner, Cooling Viscosity Bath and water bath shaker incubator shaker, circulating water bath..

water-bath

Labtro Water Bath

Microp Processor based water bath is made of thick stainless steel and has constant level of water/ low water cut off device /liquid level indicator/ drier protection device.
Labtro Water Bath has inlet and outlet drain valve / solenoid valve.

Labtro water bath maintain water at a Programmable constant temperature program. Labtro water bath used for the microbiological laboratory, laboratory water bath, rectangular water bath for incubation and shaking.

Water bath advance technology microprocessor based controller based with programmable timer. Drain Plug made from brass punctually nickel on the aspect / Back of the bath chamber. Digital water bath. Controller Indicator with visual alarm based Microprocessor based temperature Controller water level Indicator Water baths chamber filled with distilled water.

Labtro Water Bath with audio and visual alarm.

Temperature Control: Labtro Temperature Accuracy:+ 0.5 ºC, With Micro processor based Digital programmable temperature controller.

Labtro multi water baths have independent control to set temperature and time cycle. Labtro water bath control system digital with the loops. Labtro water bath have low level and liquid level indicator illumination with this control. Labtro water bath design light is on the water bath is heating. When the water bath reaches the set temperature, it will cycle on and off to maintain constant temperature with the timer cycle.

  • Labtro water bath Safety Controls
  • Overshoot temperature controls system.
  • Labtro water bath have Low temperature protection system.
  • Liquid level indicator.
  • Water level indictor with audio and video alarm.
  • Drier protection.
  • Temperature range ambient to 990c
  • Laboratory water bath chamber temperature range can be upgrade 990c to 3500c
  • Stability at 37°C +-0.1°C
  • Uniformity at 37°C +-0.1°C
  • Consumption: 220/ 230V AC offer 50Hz Single part
  • Digital Resolution: zero.1°C
  • Digital Setting: zero.1°C



Model WxDXH Holes of Dia.
LWB-6 300mmx250mmx100mm 75mm
LWB-9 300mmx350mmx100mm 75mm
LWB-12 350mmx400mmx100mm 75 mm



Labtro Cooling Cirulating Water Bath

Labtro Manufacturer , exporter and supplier of Labtro Microprocessor Technology Multi Chamber Cooling and heating Water Bath, Circulating Water Bath, water bath , digital water bath, Digital Circulating Oil Bath, Ultrasonic Cleaner, Cooling Viscosity Bath and water bath shaker incubator shaker, circulating water bath.

circulating-water-bath

Microprocessor Based Water Bath

Labtro Circulating water bath is equipped with a microprocessor Based Intelligent control system. With circulating pump (IWKI JAPAN),

Labtro Heating and cooling circulating water bath for users a working Environment where cold or heat was controlled accordingly.

Labtro temperature can be set by membranes touch the soft keys and easy to operate. The Labtro Cooling Water Bath Micro-Computer can change deviation of temperature measurements Temperature.

ALARM :-

Labtro Circulating WATER BATH is Fitted with an ultra-temperature alarm system.
Temperature Complete cycle Alarm
Time Cycle complete alarm

CIRCULATING WATER BATH Equipments specifically Designed to meet the challenging demands of various scientists for individual and specialized research applications. Over a short period of time brand have been established as reliable exporters of CIRCULATING water bath in India, catering to the vast markets in Circulating chiller South East Asia, Middle East, Africa and Europe.

Apart from that we are supplying our Circulating water bath in India, catering to a variety of customers ranging from Defense Installations, Research Laboratories, Educational Institutes and various R& D laboratories of leading national and multinational companies.

CIRCULATING water bath:

Labtro CIRCULATING water bath are double walled convection heated / cooling units.
Outer body of our Circulating water bath is constructed out of thick Stainless Steel sheet of SS 304 Grade steel.
Inside chamber of the unit is made of heavy gauge stainless steel sheet of grade ss-304.
Labtro's Circulating Chiller is provided with top opening cover, made of stainless steel with steel.

Circulation Pump :

The unit is fitted with circulation pump 5 to 15 liters/hr per Discharge Pressure 1.2 Bar, with contact parts of stainless steel brass.
Outlet Nozzle for circulation Liquid.
Microprocessor Based digital Temperature Controller.
TEMPERATURE RANGE:
Temperature range of our standard Circulating water bath models are Ambient +5 0C to 100 0C / -200 to 1000c However we have the capacity to modify the same to suit the individual specialized requirements of our customers.
Castor Wheels with Lock to have Free Handling of the Equipment.


Model No. LB101 LB105 LB205 LB201
Water Bath
Temp Range
-15~100℃ -10~100℃ -20~100℃ RT+5~100
Temp. Accuracy ±1 ℃ ±1 ℃ ±1 ℃ ±1 ℃
Capacity 6 L 5 L 5 L 12 L
Flow Rate 5~10 L/M 5~10 L/M 5~10 L/M 5~10 L
Depth 150mm 150mm 150mm 150
Calibre size W145×D130mm W140×D145mm W140×D145mm W150×D300mm
Dimensions W420×D405×H400mm W210×D405×H560mm W210×D405×H560mm W365×D340×H340



Labtro Refrigerated and heating circulating water bath

Labtro Manufacturer , exporter and supplier of Labtro Microprocessor Technology Multi Chamber Cooling and heating Water Bath, Circulating Water Bath, water bath , digital water bath, Digital Circulating Oil Bath, Ultrasonic Cleaner, Cooling Viscosity Bath and water bath shaker incubator shaker, circulating water bath.

circulating-water-bath

Refrigerated and heating circulating water bath

Working Temperature

-30 ºC to 110 ºC

Temperature stability

± 0.03 ºC

Temperature control

PID controller

Display

LED Display to set and see the Temperature parameters

Operational  Temperature

5 ºC to 40 ºC.

Low liquid cut off devices.

high temperature Cut -Off and low liquid level protection to protect the Machine from Dry Running

Cooling

Cooling Capacity at following temperatures……

  1. at room Temp. ( 20 to 22 ºC) : Cooling Capacity between 440-470  Watts.
  2. At 0 ºC :  Cooling Capacity between 300-320 Watts
  3. at  -20 ºC : Cooling Capacity between 120-150 Watts

Heating capacity

≈ 2000 Watts for fast heat -up

moderate Liquid Filling Capacity

17-20 Litres or more if required.

Circulating Pump

High quality Pump Flow rate of 16 Litres/min

option to connect the Water Bath with External system simultaneously with internal application.

Our Circulating water bath has connection for outside and inner side circulation system.

Bath Opening dimensions

22-26 (W), 28-30 (L) and 14-16 ( D)

Compressor

The Venting grill /grid or cover of compressor easily removable for Dust cleaning.

Compressor ventilation system.

The Venting system from front to back direction and not in Side venting. This feature will enable us to  place the Water Bath where sensitive instruments are placed on the side, and enable an  Uninterrupted front -back Venting

Valve

Drain port for easy removal of fluid for regular cleaning.
Circulating valve.

Supplied connection

2 barbed fittings suitable for tubing 8 and 10 mm inner dia (pump connections M10X1 Female) to be supplied with the unit
